LED SOLARIS NextGen KIT

LED SOLARIS NextGen

Extreme Durability and 4500 Lumens of Focused Power in a Modular Umbilical Dive Light

The LED SOLARIS NextGen is a high-performance primary dive light designed for the most demanding underwater conditions. With a stunning light output of up to 4500 lumens, it features a narrow 6° spot beam surrounded by a bright halo, offering both reach and ambient visibility.

It’s engineered from hard-anodized marine-grade aluminum and Delrin® polymer for full corrosion resistance, durability, and ease of handling. The head is sealed with 6 mm tempered glass, rated for depths up to 200 meters.

The light supports three output levels—BOOST, OPERATIONAL, and BACK-UP—to adapt to your diving environment and maximize burn time. A magnetic switch ensures easy and intuitive operation even with gloves.

Part of the Ammonite modular umbilical system, the SOLARIS NextGen connects to any compatible cable and battery from the Ammonite range. This modularity ensures upgradeability, serviceability, and configuration flexibility, with field-replaceable cables and futureproof compatibility.

Intelligent electronics detect battery levels and activate a “Take Me Home” mode when power is low, reducing output to 20% and flashing a warning. This ensures you’re never left in the dark, and light continues operating until recharge.

Features:

Up to 4500 lumens in a focused 6° spot beam
3 output modes: BOOST, OPERATIONAL, BACK-UP
Magnetic switch with easy glove operation
Modular chinch-type connector system
Hard-anodized aluminum & Delrin® construction
“Take Me Home” emergency mode for low battery
Durable, lightweight, and ultra-compact

Technical Specifications:

Light Output	Up to 4500 lumens
Beam Angle	6° spot + bright spill
Color Temperature	Cool white
Light Modes	BOOST / OPERATIONAL / BACK-UP
Take Me Home Mode	20% emergency output
Material	Hard-anodized aluminum / Delrin®
Length / Diameter	117 mm / 61 mm
Weight	340 g (130 g in water)
Switch	Magnetic switch
Depth Rating	200 m (ACCU TYPE 24 SPECIAL battery)
Light Source	5 × CREE® XPL LEDs

Downloads:
